How to replace the Shift Cable for the Automatic Transmission Range Selector on Chevrolet Colorado?

The fixation of a new Shift Cable should begin by placing the vehicle in park position then elevating and securing the vehicle. Doing not pull on the boot section of the cable should be avoided. You must disconnect the Shift Cable from the transmission range selector lever ball stud by using a flat bladed tool to split the Shift Cable end from the range selector lever. Pull the retainer from the Shift Cable then use the fingers to depress its locking tabs which will release the bracket. Cable grommet should now be pushed through the floor panel while simultaneously lowering the vehicle. You need to remove the left hinge pillar panel trim followed by raising the driver-side carpet so you can access the Shift Cable. A flat bladed tool should be used to disconnect the Shift Cable retainer from the lower dash panel and once again disconnect the Shift Cable from the transmission range selector lever ball stud by prying the Shift Cable end away from the lever. Begin by removing the retainer from the Shift Cable and push the locking tabs inward to detach from the steering column bracket before taking out the Shift Cable from the vehicle. Sitting the cable grommet under the floor panel first allows you to guide the Shift Cable below the dash mat until you can connect the Shift Cable retainer to the lower dash panel. Rout the Shift Cable through the steering column bracket while also fitting the retainer around the Shift Cable. Reposition the driver's side carpet after securing the Shift Cable end onto the ball stud of the lever with a check below the pedal to confirm complete motion. The vehicle needs to be raised for installation of the left hinge pillar trim panel followed by Shift Cable bracket connection and Shift Cable retainer attachment. To implement a new cable system the operator should first discard the primary lockout pin then adjust the Shift Cable before lowering the vehicle.

How to replace the Shift Cable on a 2ML70 automatic transmission on Chevrolet Tahoe?

Starting the repair of a 2ml70 automatic transmission range selector lever cable requires placing the Steering Column shift lever to park position then unfastening the instrument panel knee bolster and driver seat before removing the body hinge pillar trim panel. Start by pulling back carpet and insulation in the driver area before using an appropriate tool to remove the cable retainer from the Steering Column bracket and detached the cable end from the Steering Column ball stud. Then release the tangs to extract the cable while preventing unnecessary range selector cable twisting or bending. Use this step to remove the support-based range selector cable as well as the cable grommet from the floor panel. Support the vehicle while rising it and detach the cable's clips from the reinforcement panel and the range selector lever cable heat shield bolts before removing the heat shield. The vehicle should have its transmission manual shaft positioned to mechanical park as the installer disconnects the range select lever cable from the range select lever before removing the cable retainer and cable from the cable bracket. Attach the transmission range selector cable to the vehicle while maintaining the transmission manual shaft lever in mechanical park before installing the range selector lever cable to the cable bracket and securing it with the retainer. Fasten the heat shield over the transmission with bolts and tighten them to 17 nm (13 lb ft). Do the vehicle drop and position the clips at the cable ends on the floor panel reinforcement when also keeping the Steering Column shift lever in park. The floor panel receives the cable grommet while the range selector cable becomes attached to its support before connecting to the Steering Column bracket until tangs fully hook in. The final step consists of attaching the cable end to the Steering Column ball stud followed by retaining the cable with its metal clip. After that install the carpet and insulation before replacing the body hinge pillar trim panel, driver seat, and instrument panel knee bolster. Perform a transmission shift test before adjusting the cable unless all gears fail to activate.

OEM Chevrolet Shift Cable

Transmission Shift Cable

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

159 Shift Cables found

View related parts
Chevrolet Control Cable Part Number: 23256076
$43.92 MSRP: $76.64
You Save: $32.72 (43%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cable Assembly-Automatic Transmission Range Selector Lever; Automatic Transmission Shifter Cable
- Replaces: 20922587, 22833771, 22977291, 25824455, 25882560, 25809651
Fits the following Chevrolet Models:
- Traverse | 2009-2017 | LS, LT, LTZ, Premier | 6 Cyl 3.6 L GAS
View related parts
Chevrolet Shift Control Cable Part Number: 20787606
$46.89 MSRP: $81.81
You Save: $34.92 (43%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cable Assembly-Automatic Transmission Range Selector Lever (At Transmission); Automatic Transmission Shifter Cable; Cable, Transmission Control Cable
Fits the following Chevrolet Models:
- Silverado 1500 | 2010-2013 | Hybrid, LS, LT, LTZ, WT, XFE | 6 Cyl 4.3 L GAS, 8 Cyl 4.8 L FLEX, 8 Cyl 5.3 L FLEX, 8 Cyl 6.0 L FULL HYBRID EV-FLEX (FHEV), 8 Cyl 6.2 L FLEX
- Suburban 1500 | 2007-2008 | LS, LT, LTZ | 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS
- Suburban 2500 | 2007-2008 | LS, LT, LTZ | 8 Cyl 6.0 L GAS
- Tahoe | 2007-2008 | LS, LT, LTZ | 8 Cyl 4.8 L GAS, 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS, 8 Cyl 6.2 L GAS
View More
View related parts
Chevrolet Shift Control Cable Part Number: 20787609
$47.30 MSRP: $82.55
You Save: $35.25 (43%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cable Assembly-Automatic Transmission Range Selector Lever (At Transmission); Automatic Transmission Shifter Cable
Fits the following Chevrolet Models:
- Avalanche | 2009-2013 | Black Diamond LS, Black Diamond LT, Black Diamond LTZ, LS, LT, LTZ | 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS
- Suburban 1500 | 2009-2014 | LS, LT, LTZ | 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS
- Suburban 2500 | 2009-2013 | LS, LT | 8 Cyl 6.0 L FLEX, 8 Cyl 6.0 L GAS
- Tahoe | 2009-2014 | LS, LT, LTZ, PPV | 8 Cyl 4.8 L GAS, 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS, 8 Cyl 6.2 L FLEX
View More
View related parts
Chevrolet Shift Control Cable Part Number: 25995571
$47.35 MSRP: $82.62
You Save: $35.27 (43%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cable Assembly-Automatic Transmission Range Selector Lever (At Transmission); Automatic Transmission Shifter Cable
Fits the following Chevrolet Models:
- Silverado 2500 HD | 2010-2014 | LT, LTZ, WT | 8 Cyl 6.0 L CNG, 8 Cyl 6.0 L FLEX, 8 Cyl 6.0 L GAS, 8 Cyl 6.6 L DIESEL
- Silverado 3500 HD | 2011-2014 | LT, LTZ, WT | 8 Cyl 6.0 L FLEX, 8 Cyl 6.0 L GAS, 8 Cyl 6.6 L DIESEL
View related parts
Chevrolet Shift Control Cable Part Number: 23295736
$47.59 MSRP: $82.25
You Save: $34.66 (43%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cable Assembly-Automatic Transmission Range Selector Lever; Automatic Transmission Shifter Cable; Cable, Transmission Shift Control Cable
- Replaces: 22890115, 22737403, 20817476, 20920071
Fits the following Chevrolet Models:
- Equinox | 2010-2017 | L, LS, LT, LTZ, Premier | 4 Cyl 2.4 L FLEX, 4 Cyl 2.4 L GAS, 6 Cyl 3.0 L FLEX, 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS
View related parts
Chevrolet Shift Control Cable Part Number: 20782446
$48.93 MSRP: $85.38
You Save: $36.45 (43%)
ADD TO CART
Product Specifications
- Other Name: Cable Assembly-Automatic Transmission Range Selector Lever; Automatic Transmission Shifter Cable; Cable, Transmission Shift Control Cable
- Replaces: 15888331
Fits the following Chevrolet Models:
- Corvette | 2006-2013 | 427, 427 Limited Edition Z06, Base, Grand Sport, Z06, Z06 Carbon, ZR1 | 8 Cyl 6.0 L GAS, 8 Cyl 6.2 L GAS, 8 Cyl 7.0 L GAS
View related parts
Chevrolet Control Cable Part Number: 84125980
$55.20 MSRP: $96.33
You Save: $41.13 (43%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cable Assembly-Automatic Transmission Range Selector Lever; Automatic Transmission Shifter Cable
- Replaces: 23321785, 23211892
Fits the following Chevrolet Models:
- Corvette | 2015-2019 | Grand Sport, Stingray, Z06, ZR1 | 8 Cyl 6.2 L GAS
View related parts
Chevrolet Shift Control Cable Part Number: 20787611
$55.49 MSRP: $96.85
You Save: $41.36 (43%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cable Assembly-Automatic Transmission Range Selector Lever (At Transmission); Automatic Transmission Shifter Cable
- Replaces: 15945100
Fits the following Chevrolet Models:
- Silverado 1500 | 2007-2013 | Hybrid, LS, LT, LTZ, WT, XFE | 6 Cyl 4.3 L GAS, 8 Cyl 4.8 L FLEX, 8 Cyl 4.8 L GAS, 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L FULL HYBRID EV-FLEX (FHEV), 8 Cyl 6.0 L GAS, 8 Cyl 6.2 L FLEX
- Silverado 2500 HD | 2007-2014 | LT, LTZ, WT | 8 Cyl 6.0 L CNG, 8 Cyl 6.0 L FLEX, 8 Cyl 6.0 L GAS, 8 Cyl 6.6 L DIESEL
- Silverado 3500 HD | 2007-2014 | LT, LTZ, WT | 8 Cyl 6.0 L FLEX, 8 Cyl 6.0 L GAS, 8 Cyl 6.6 L DIESEL
- Suburban 1500 | 2008-2013 | LS, LT, LTZ | 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS
- Suburban 2500 | 2008-2013 | LS, LT | 8 Cyl 6.0 L FLEX, 8 Cyl 6.0 L GAS
View More
View related parts
Chevrolet Shift Control Cable Part Number: 84507731
$58.53 MSRP: $102.14
You Save: $43.61 (43%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cable Assembly-Automatic Transmission Range Selector Lever (At Transmission); Automatic Transmission Shifter Cable
- Replaces: 23258955
Fits the following Chevrolet Models:
- Silverado 1500 | 2016-2018 | Custom, High Country, LS, LT, LTZ, SSV, WT | 6 Cyl 4.3 L FLEX, 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS, 8 Cyl 5.3 L MILD HYBRID EV-GAS (MHEV), 8 Cyl 6.2 L GAS
- Silverado 2500 HD | 2016-2019 | High Country, LT, LTZ, WT | 8 Cyl 6.0 L CNG, 8 Cyl 6.0 L FLEX, 8 Cyl 6.0 L GAS, 8 Cyl 6.6 L DIESEL
- Silverado 3500 HD | 2016-2019 | High Country, LT, LTZ, WT | 8 Cyl 6.0 L CNG, 8 Cyl 6.0 L FLEX, 8 Cyl 6.0 L GAS, 8 Cyl 6.6 L DIESEL
- Suburban | 2016-2020 | LS, LT, LTZ, Premier | 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS, 8 Cyl 6.2 L FLEX, 8 Cyl 6.2 L GAS
- Suburban 3500 HD | 2016-2019 | LS, LT | 8 Cyl 6.0 L FLEX, 8 Cyl 6.0 L GAS
- Tahoe | 2016-2020 | LS, LT, LTZ, PPV, Premier, SSV | 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS, 8 Cyl 6.2 L FLEX, 8 Cyl 6.2 L GAS
View More
View related parts
Chevrolet Shift Control Cable Part Number: 25800703
$62.35 MSRP: $108.88
You Save: $46.53 (43%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cable Assembly-Automatic Transmission Range Selector Lever; Automatic Transmission Shifter Cable; Cable, Transmission Shift Control Cable
Fits the following Chevrolet Models:
- Colorado | 2009-2012 | LT, WT | 4 Cyl 2.9 L GAS, 5 Cyl 3.7 L GAS
View related parts
Chevrolet Shift Control Cable Part Number: 25800701
$73.49 MSRP: $128.22
You Save: $54.73 (43%)
ADD TO CART
Product Specifications
- Other Name: Cable Assembly-Automatic Transmission Range Selector Lever; Automatic Transmission Shifter Cable; Cable, Transmission Shift Control Cable
- Replaces: 15867641, 15124555
Fits the following Chevrolet Models:
- Colorado | 2004-2008 | Base, LS, LT, Sport, Sport LS, WT, Z71, Z71 LS, Z85, Z85 LS | 4 Cyl 2.8 L GAS, 4 Cyl 2.9 L GAS, 5 Cyl 3.5 L GAS, 5 Cyl 3.7 L GAS
View related parts
Chevrolet Shift Control Cable Part Number: 15785087
$77.33 MSRP: $134.94
You Save: $57.61 (43%)
ADD TO CART
Product Specifications
- Other Name: Cable, Automatic Transmission Range Selector Lever; Automatic Transmission Shifter Cable; Cable, Transmission Shift Control Cable
- Replaces: 10357836, 15094156, 15079394, 15101412, 15190386
Fits the following Chevrolet Models:
- SSR | 2003-2006 | Base | 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS
- Trailblazer | 2002-2009 | Base, LS, LT, LTZ, North Face, SS | 6 Cyl 4.2 L GAS, 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS
- Trailblazer EXT | 2002-2006 | LS, LT, North Face | 6 Cyl 4.2 L GAS, 8 Cyl 5.3 L GAS
View More
View related parts
Chevrolet Shift Control Cable Part Number: 10352529
$77.55 MSRP: $135.33
You Save: $57.78 (43%)
ADD TO CART
Product Specifications
- Other Name: Cable Assembly-Automatic Transmission Range Selector Lever; Automatic Transmission Shifter Cable; Cable, Transmission Shift Control Cable
Fits the following Chevrolet Models:
- Corvette | 2005 | Base | 8 Cyl 6.0 L GAS
View related parts
Chevrolet Shift Control Cable Part Number: 20787607
$87.46 MSRP: $152.61
You Save: $65.15 (43%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cable Assembly-Automatic Transmission Range Selector Lever (At Transmission); Automatic Transmission Shifter Cable
Fits the following Chevrolet Models:
- Suburban 1500 | 2007-2008 | LS, LT, LTZ | 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS
- Suburban 2500 | 2007-2008 | LS, LT, LTZ | 8 Cyl 6.0 L GAS
- Tahoe | 2007-2009 | LS, LT, LTZ, PPV | 8 Cyl 4.8 L GAS, 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS, 8 Cyl 6.2 L FLEX, 8 Cyl 6.2 L GAS
View More
View related parts
Chevrolet Control Cable Part Number: 25193527
$94.10 MSRP: $162.94
You Save: $68.84 (43%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cable, Transmission Shift Control Cable
- Replaces: 25183815, 25185859, 25192294, 25182316, 25184765, 25186261, 25189485
Fits the following Chevrolet Models:
- Cruze | 2011-2015 | Diesel, Eco, L, LS, LT, LTZ | 4 Cyl 1.4 L GAS, 4 Cyl 1.8 L FLEX, 4 Cyl 1.8 L GAS, 4 Cyl 2.0 L DIESEL
- Cruze Limited | 2016 | Eco, L, LS, LT, LTZ | 4 Cyl 1.4 L GAS, 4 Cyl 1.8 L FLEX, 4 Cyl 1.8 L GAS
View related parts
Chevrolet Shift Cable Part Number: 15037353
$95.89 MSRP: $167.36
You Save: $71.47 (43%)
ADD TO CART
Product Specifications
- Other Name: Cable, Automatic Transmission Range Selector Lever
Fits the following Chevrolet Models:
- Silverado 1500 | 1999-2000 | Base, LS, LT | 6 Cyl 4.3 L GAS, 8 Cyl 4.8 L GAS, 8 Cyl 5.3 L GAS
- Silverado 2500 | 1999-2000 | Base, LS, LT | 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS
- Suburban 1500 | 2000 | Base, LS, LT | 8 Cyl 5.3 L GAS
- Suburban 2500 | 2000 | Base, LS, LT | 8 Cyl 6.0 L GAS
- Tahoe | 2000 | Base, LS, LT, Limited, Z71 | 8 Cyl 4.8 L GAS, 8 Cyl 5.3 L GAS, 8 Cyl 5.7 L GAS
View More
View related parts
Chevrolet Shift Control Cable Part Number: 20787608
$59.43 MSRP: $101.41
You Save: $41.98 (42%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cable Assembly-Automatic Transmission Range Selector Lever (At Transmission); Automatic Transmission Shifter Cable
Fits the following Chevrolet Models:
- Avalanche | 2009-2013 | Black Diamond LS, Black Diamond LT, Black Diamond LTZ, LS, LT, LTZ | 8 Cyl 5.3 L FLEX, 8 Cyl 6.0 L GAS
- Silverado 1500 | 2010-2013 | Hybrid, LS, LT, LTZ, WT, XFE | 6 Cyl 4.3 L GAS, 8 Cyl 4.8 L FLEX, 8 Cyl 5.3 L FLEX, 8 Cyl 6.0 L FULL HYBRID EV-FLEX (FHEV), 8 Cyl 6.2 L FLEX
- Silverado 2500 HD | 2010-2014 | LT, LTZ, WT | 8 Cyl 6.0 L CNG, 8 Cyl 6.0 L FLEX, 8 Cyl 6.0 L GAS, 8 Cyl 6.6 L DIESEL
- Silverado 3500 HD | 2010-2014 | LT, LTZ, WT | 8 Cyl 6.0 L FLEX, 8 Cyl 6.0 L GAS, 8 Cyl 6.6 L DIESEL
- Suburban 1500 | 2007-2014 | LS, LT, LTZ | 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS
- Suburban 2500 | 2007-2013 | LS, LT, LTZ | 8 Cyl 6.0 L FLEX, 8 Cyl 6.0 L GAS
- Tahoe | 2007-2014 | LS, LT, LTZ, SSV | 8 Cyl 4.8 L GAS, 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS, 8 Cyl 6.2 L FLEX, 8 Cyl 6.2 L GAS
View More
View related parts
Chevrolet Shift Control Cable Part Number: 19368078
$78.17 MSRP: $133.08
You Save: $54.91 (42%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cable Assembly, Automatic Transmission Range Selector Lever; Automatic Transmission Shifter Cable; Cable, Transmission Shift Control Cable
- Replaces: 10340403, 12565602, 15299671
Fits the following Chevrolet Models:
- Uplander | 2005-2008 | Base, LS, LT | 6 Cyl 3.5 L GAS, 6 Cyl 3.9 L FLEX, 6 Cyl 3.9 L GAS
View related parts
Chevrolet Shift Control Cable Part Number: 23249984
$24.41 MSRP: $40.21
You Save: $15.80 (40%)
Ships in 1 Business Day
ADD TO CART
Product Specifications
- Other Name: Cable Kit-Automatic Transmission Range Selector Lever; Cable Kit, Transmission Shift Control Cable
- Replaces: 10358324, 15218472, 15856648, 15927144
Fits the following Chevrolet Models:
- Malibu | 2005-2006 | Base, LS, LT, Maxx LS, Maxx LT, Maxx SS, SS | 4 Cyl 2.2 L GAS, 6 Cyl 3.5 L GAS, 6 Cyl 3.9 L GAS
View related parts
Chevrolet Shift Control Cable Part Number: 84133622
$29.80 MSRP: $49.09
You Save: $19.29 (40%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cable Assembly-Automatic Transmission Range Selector Lever; Automatic Transmission Shifter Cable
- Replaces: 23461534, 84377163, 84573362
Fits the following Chevrolet Models:
- Colorado | 2015-2020 | Base, LT, WT, Z71, ZR2 | 4 Cyl 2.5 L GAS, 4 Cyl 2.8 L DIESEL, 6 Cyl 3.6 L GAS

| Page 1 of 8 |Next >

1-20 of 159 Results

Chevrolet Shift Cable

Choose OEM Shift Cable, you're making the optimal decision for superior quality and perfect performance. You can feel confident because each component goes through stringent quality checks. Every part is carefully built to comply with Chevrolet's factory specifications. You'll enjoy a smooth, worry-free installation that fits just right. At ChevyPartsDeal.com, you'll find it easy to get top-quality OEM Chevrolet Shift Cable. You can shop at highly competitive prices and protect your budget. All our genuine Chevrolet parts include a dependable manufacturer's warranty. You'll also appreciate our straightforward return policy and swift delivery services for extra convenience.

Chevrolet Shift Cable will lock the gears in the right positions when every lever press is met with precision. Since 1911, Chevy has been pursuing a rational power, launching trucks and sedans that are capable of being applied by ordinary drivers without any hassle. Since hard little blocks to the new Super Cruise lane keeper, the company continues stacking actual upgrades more than flashy razzle-dazzle. Individuals rely on Chevrolet in long distance journeys since its cabins remain silent, engines drag hard, and its prices remain reasonable. Chevy also listens, with phone mirroring, stylishly dressed, and efficient fuel economy to ensure first cars and family haulers feel right as well. Each of the new launches has a brand that attempts to strike a balance between fresh technology and components that can be serviced easily at home and retain ownership. The Shift Cable is a transmission cable that connects between your shifter handle and transmission case and switches your hand movement to transmission movement, which is crisp and mechanical and which is sheathed in low-friction lining so that it does not stretch, does not heat, and does not get sprayed by the road many miles. Once a frayed strand or sticky joint is noticed, the Shift Cable gives you a warning of sloppy travel of a lever long before gears start grinding. Chevy owners can change it very fast and they feel like the lever is going back to factory fresh. Periodical check helps to identify wear early enough before Chevrolet drivers create stunts on the road.

Chevrolet Shift Cable Parts and Q&A

Shift Control Cable
25800701
Q: How to replace the Shift Cable for the Automatic Transmission Range Selector on Chevrolet Colorado?
A:
The fixation of a new Shift Cable should begin by placing the vehicle in park position then elevating and securing the vehicle. Doing not pull on the boot section of the cable should be avoided. You must disconnect the Shift Cable from the transmission range selector lever ball stud by using a flat bladed tool to split the Shift Cable end from the range selector lever. Pull the retainer from the Shift Cable then use the fingers to depress its locking tabs which will release the bracket. Cable grommet should now be pushed through the floor panel while simultaneously lowering the vehicle. You need to remove the left hinge pillar panel trim followed by raising the driver-side carpet so you can access the Shift Cable. A flat bladed tool should be used to disconnect the Shift Cable retainer from the lower dash panel and once again disconnect the Shift Cable from the transmission range selector lever ball stud by prying the Shift Cable end away from the lever. Begin by removing the retainer from the Shift Cable and push the locking tabs inward to detach from the steering column bracket before taking out the Shift Cable from the vehicle. Sitting the cable grommet under the floor panel first allows you to guide the Shift Cable below the dash mat until you can connect the Shift Cable retainer to the lower dash panel. Rout the Shift Cable through the steering column bracket while also fitting the retainer around the Shift Cable. Reposition the driver's side carpet after securing the Shift Cable end onto the ball stud of the lever with a check below the pedal to confirm complete motion. The vehicle needs to be raised for installation of the left hinge pillar trim panel followed by Shift Cable bracket connection and Shift Cable retainer attachment. To implement a new cable system the operator should first discard the primary lockout pin then adjust the Shift Cable before lowering the vehicle.
Shift Control Cable
20787607
Q: How to replace the Shift Cable on a 2ML70 automatic transmission on Chevrolet Tahoe?
A:
Starting the repair of a 2ml70 automatic transmission range selector lever cable requires placing the Steering Column shift lever to park position then unfastening the instrument panel knee bolster and driver seat before removing the body hinge pillar trim panel. Start by pulling back carpet and insulation in the driver area before using an appropriate tool to remove the cable retainer from the Steering Column bracket and detached the cable end from the Steering Column ball stud. Then release the tangs to extract the cable while preventing unnecessary range selector cable twisting or bending. Use this step to remove the support-based range selector cable as well as the cable grommet from the floor panel. Support the vehicle while rising it and detach the cable's clips from the reinforcement panel and the range selector lever cable heat shield bolts before removing the heat shield. The vehicle should have its transmission manual shaft positioned to mechanical park as the installer disconnects the range select lever cable from the range select lever before removing the cable retainer and cable from the cable bracket. Attach the transmission range selector cable to the vehicle while maintaining the transmission manual shaft lever in mechanical park before installing the range selector lever cable to the cable bracket and securing it with the retainer. Fasten the heat shield over the transmission with bolts and tighten them to 17 nm (13 lb ft). Do the vehicle drop and position the clips at the cable ends on the floor panel reinforcement when also keeping the Steering Column shift lever in park. The floor panel receives the cable grommet while the range selector cable becomes attached to its support before connecting to the Steering Column bracket until tangs fully hook in. The final step consists of attaching the cable end to the Steering Column ball stud followed by retaining the cable with its metal clip. After that install the carpet and insulation before replacing the body hinge pillar trim panel, driver seat, and instrument panel knee bolster. Perform a transmission shift test before adjusting the cable unless all gears fail to activate.
