How to replace the lower ball joint on Chevrolet Equinox?

You need to install the lower Control Arm securely to work on the lower Ball Joint. Use a 5/16 and a 31/64 inch drill bit to pass through Ball Joint rivets before enlarging both holes with the same 31/64 inch drill bit and brushing away remaining burs from the Control Arm. When you extract the Ball Joint from its position take note of its exact location for reinstalling it. Install the replacement Ball Joint after cleaning the Control Arm from impurities and using the same steps used during the disassembly phase. Install the new Ball Joint hardware pieces using the accompanying hardware and making sure bolts enter through the Ball Joint from its top side. Place the lower Control Arm back then tighten bolts and nuts to 68 nm (50 ft. Lbs. Torques).

OEM Chevrolet Equinox Ball Joint

Control Arm Joint

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

2 Ball Joints found

View related parts
Chevrolet Equinox Lower Ball Joint, Front Part Number: 19258791
$40.36 MSRP: $69.30
You Save: $28.94 (42%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Stud Kit, Front Lower Control Arm Ball; Suspension Ball Joint; Ball Joint; Stud, Front Wheel Lower Control Arm
- Position: Front Lower
- Replaces: 25872808
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2010-2017 Chevrolet Equinox | L, LS, LT, LTZ, Premier | 4 Cyl 2.4 L FLEX, 4 Cyl 2.4 L GAS, 6 Cyl 3.0 L FLEX, 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS
View related parts
Chevrolet Equinox Ball Joint Part Number: 88965333
$48.48 MSRP: $82.54
You Save: $34.06 (42%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Stud Kit, Front Lower Control Arm Ball; Suspension Ball Joint; Lower Ball Joint; Stud Kit, Steering Knuckle Lower Control Arm Pivot; Stud Kit, Front Wheel Lower Control Arm
- Position: Front Lower
- Replaces: 88955451, 22157089
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2005-2009 Chevrolet Equinox | LS, LT, LTZ, Sport | 6 Cyl 3.4 L GAS, 6 Cyl 3.6 L GAS

Chevrolet Equinox Ball Joint

Want to cut long-term maintenance and repair costs? Choose OEM Ball Joint. Those parts deliver top durability you can trust. On our site, you'll find a huge catalog of genuine Chevrolet Equinox parts. Prices are unbeatable, so you can keep more in your pocket. Every OEM Chevrolet Equinox Ball Joint includes a manufacturer's warranty. You can also get an easy return policy that keeps buying risk free. Fast delivery, get your car on the road quickly. It's simple to search, compare, and order. Stop guessing about quality or fit. Order today and save with parts that last.

The Ball Joint of Chevrolet Equinox cars are imperative components in the suspension and steering systems of the cars where it links the control arms to the steering knuckles allowing free rotation in two planes but inhibiting translation. Usually, Equinox cars use upper and lower ball joints within their suspensions, and the upper ones normally act as the followers. Born of steel these eyebars have a bearing stud and socket with a rubber boot to shield from dirt and allow the passage of lubrication. Kingpin had earlier been used but has been replaced partly by ball joints where meeting of caster and camber can be adjusted significantly improving the behavior of the vehicle, stability and comfort of ride. Ball joint being one of the most significant constraints of this modern advancements is commonly manufactured as a sealed for life type that does not require frequent lubrication hence elongating the service interval.

Chevrolet Equinox Ball Joint Parts and Q&A

Ball Joint
88965333
Q: How to replace the lower ball joint on Chevrolet Equinox?
A:
You need to install the lower Control Arm securely to work on the lower Ball Joint. Use a 5/16 and a 31/64 inch drill bit to pass through Ball Joint rivets before enlarging both holes with the same 31/64 inch drill bit and brushing away remaining burs from the Control Arm. When you extract the Ball Joint from its position take note of its exact location for reinstalling it. Install the replacement Ball Joint after cleaning the Control Arm from impurities and using the same steps used during the disassembly phase. Install the new Ball Joint hardware pieces using the accompanying hardware and making sure bolts enter through the Ball Joint from its top side. Place the lower Control Arm back then tighten bolts and nuts to 68 nm (50 ft. Lbs. Torques).
