Question 1

How to replace the oil pump and crankshaft seal in 3.2L V6 engine on Cadillac CTS?

Accepted Answer

Empty the engine oil and extract the oil filter, then also remove the timing belt and the crankshaft drive gear. After that, it is necessary to eliminate the oil pan and to unscrew the oil pressure sending unit. Remove the mounting fasteners of the oil pick-up tube and get rid of the O-ring located in the groove of the tube. Remove the upper alternator mounting bolt, then taken out the lower bolt and swing the alternator aside while tightening the upper bolt. If still further space is desired, the alternator should be eliminee. Take out the oil pump-to-engine mounting bolts and then take off the pump, using a thin flat to free it between the front main bearing cap and the body of the pump, if you have to. Remove the relief valve plug, the spring, the 'O' ring and then the relief valve itself. The bolts holding the oil pump cover need to be removed and the cover as well as the oil pump drive rotor, and the driven rotor. Remove all parts and clean with solvent and visually check for signs of wear and damage, oil the relief valve and ensure that it drops freely in the bore provided. Inspect oil pressure relief valve, sliding surface and valve spring and since they are used as a set, replace them if faulty. Using the feeler gauge to ensure proper dimension check on clearance such as the clearance between the driven rotor to the oil pump body, rotor side clearance and rotor tip clearance, the worn parts were replaced or even disposed the entire oil pump assembly if compromised. Remove the old crankshaft seal from the timing chain cover and lubricate the outer perimeter of the new crank seal with MP grease or engine oil then gently instal it. Grease the seal lip and put petroleum jelly on the pump drive and driven rotors then fit them in timing chain cover (pump faces out). After this, apply petroleum jelly into the pump cavity to assist in pringing then fit the cover and finally tighten the cover bolts up to the requisite torque. Clean the oil pressure relief valve with the new clean engine oil, fit the valve and spring into the pump cover then fitted the plug. After reinstalling all the following processes are done in the reverse order that they were removed, and all gaskets used during the process are new ones; tightening oil pump mounting bolts are done by the cross pattern; when fixing the oil pan, a new filter is installed and the crankcase is filled with fresh oil. Last of all, examine the status of the oil warning lights in the instrument panel after the car has been started and allowed to run in idle for a while.

Question 2

How to remove and install the timing chain cover and oil pump in V8 engine on Cadillac Escalade?

Accepted Answer

To remove the timing chain cover and, for 6.0L models, the oil pan, start by taking off the oil pump pick-up tube mounting nuts and bolts, then lower the pick-up tube and screen assembly from the vehicle, ensuring to remove the bolt securing the oil pick-up tube to the oil pump. Next, for 6.0L models, take out the oil pump retaining bolts and slide the pump off the end of the crankshaft. For 5.3L and 6.2L models, install special tool EN-51257 against the timing chain tensioner and the edge of the oil pump body, tightening the mounting bolts securely. It is crucial for 5.3L and 6.2L models that if the oil pump is removed without replacement, special tool EN-51267 must be installed to maintain alignment until reinstallation; otherwise, a new oil pump is required. After removing the oil pump cover, withdraw the rotors and clean all components thoroughly, inspecting for damage, particularly on bolt holes and splined surfaces; replace the entire oil pump assembly if any components are scored or worn. To install, prime the pump with clean engine oil while turning it by hand, then position the oil pump over the crankshaft, ensuring proper alignment with the crankshaft sprocket. For 5.3L and 6.2L models, maintain contact between the pump body and the alignment tool while tightening the bolts, ensuring no gap exists. Install and torque the oil pump mounting bolts, then attach a new O-ring to the oil pump pick-up tube, fastening it securely to prevent air from entering the oiling system. Finally, align and install the timing chain cover and oil pan for 6.0L models, complete the installation in reverse order, add oil and coolant as needed, and run the engine to check for leaks and oil pressure.

OEM Cadillac Oil Pump

32 Oil Pumps found

Cadillac Oil Pump Part Number: 93442037

Cadillac Oil Pump Part Number: 12697425

Cadillac Oil Pump Part Number: 12698586

Cadillac Oil Pump Part Number: 55508996

Cadillac Oil Pump Part Number: 12696174

Cadillac Oil Pump Part Number: 12590890

Cadillac Oil Pump Part Number: 12555384

Cadillac Oil Pump Part Number: 9193203

Cadillac Oil Pump Part Number: 22524576

Cadillac Oil Pump Part Number: 12366109

Cadillac Oil Pump Part Number: 22524583

Cadillac Water Pump Part Number: 12566029

Cadillac Oil Pump Part Number: 22525287

Cadillac Oil Pump Part Number: 12731660

Cadillac Oil Pump Part Number: 3517442

Cadillac Oil Pump Part Number: 12603243

Cadillac Oil Pump Part Number: 3535211

Cadillac Oil Pump Part Number: 3517753

Cadillac Oil Pump Part Number: 14086060

Cadillac Oil Pump Part Number: 90571901

Cadillac Oil Pump
