OEM Cadillac DeVille Canister Purge Valves

Cadillac DeVille Canister Purge Valves Parts and Q&A

• Solenoid Valve
  12581282
  Q: How to replace the canister purge valves on Cadillac DeVille?

  A:

  To replace the evap canister purge solenoid valve, you should first disconnect the evaporative emission (EVAP) canister purge valve electrical connector and the evap purge pipe as on the evap canister purge valve. Take the-runtime throttle and loosen its-retaining bolt, then pull it out, and set aside from the Intake Manifold while separating the evap canister purge valve from the said-peak. For installation, once more, open the throttle but not entirely then don't forget to install a fresh o-ring on the evap purge valve. Mount the evap canister purge valve on the Intake Manifold and fasten the retaining bolt with a tension of 12 n.m (106 lb in). Reach-down and close the throttle, then join the evap purge pipe to the evap canister purge valve and finally reconnect evap canister purge valve electrical connector to itself.
• Purge Valve
  1997279
  Q: How to Service Canister Purge Valves on Cadillac DeVille?

  A:

  Service operations of the Canister Purge Valves start with detaching the electrical connector from the evap purge solenoid while taking out intake manifold sight shield nuts from the intake manifold sight shield. Start by taking away the evap purge pipe from the evap purge solenoid while leaving the throttle partially open. After that, uninstall the retaining bolt from the evap purge solenoid before extracting the valve from the intake manifold. Start by installing a replacement o-ring to the evap purge solenoid then partially open the throttle prior to placing the evap purge solenoid inside the intake manifold. After placing the new o-ring on the evap purge solenoid you should insert its retaining bolt and torque it until it reaches 10 n.m (88 lb in). The throttle must be partially opened while you join the evap purge solenoid hose and electrical connector to their respective points on the solenoid. You should reinstall and secure the intake manifold sight shield to the engine by using the intake manifold sight shield nuts while keeping them at 3 n.m (27 lb in) torque settings.
