Make sure this part fits

GM 19420713
Throttle Body

2002-2007 GM

Customer Questions & Expert Answers (26)
GM 19420713 Throttle Body
  • Part Description
    Body, Fuel Injection Air Meter
  • Replaces
    12679525, 12570800
  • Manufacturer
    General Motors
Make sure this part fits
$196.41 MSRP: $398.92
You Save: $202.51 (51%)
Ships in 1-3 Business Days
1
ADD TO CART
  • 2007 Chevy Express 1500 Throttle Body Diagram for 19420713
    The diagram listed above is for your reference. View diagram for your vehicle

    Related Parts for 19420713

  • Vehicle Fitment

    Year Make Model Trim Engine
    2004 Buick RainierCXL, CXL Plus8 Cyl 5.3 L GAS
    2002-2006 Cadillac EscaladeBase8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS
    2003-2006 Cadillac Escalade ESVBase8 Cyl 6.0 L GAS
    2002-2006 Cadillac Escalade EXTBase8 Cyl 6.0 L GAS
    2002-2006 Chevrolet Avalanche 1500Base, LS, LT, North Face, On Road Edition, WBH, Z66, Z718 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS
    2002-2006 Chevrolet Avalanche 2500Base, LS, LT8 Cyl 8.1 L GAS
    2007 Chevrolet Express 1500Base
    2004-2007 Chevrolet Express 2500Base, LS, LT8 Cyl 4.8 L GAS, 8 Cyl 6.0 L CNG, 8 Cyl 6.0 L GAS
    2004-2007 Chevrolet Express 3500Base, LS, LT8 Cyl 4.8 L GAS, 8 Cyl 6.0 L CNG, 8 Cyl 6.0 L GAS
    2003-2004 Chevrolet SSRBase8 Cyl 5.3 L GAS
    View More
    Warning: California's Proposition 65

  • Customer Questions & Expert Answers

    Q:
    Is this 19420713 designed for my car? Posted by ChevyPartsDeal Specialist
    A:
    Please Select Your Vehicle model to see if part number 19420713 is suitable before ordering.
    Posted by ChevyPartsDeal Specialist
    Q:
    What is the first step to replace the throttle body assembly for the 2004 Buick Rainier? Posted by Customer
    A:
    First, remove the resonator assembly.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What should be done before removing the air intake duct for the 2002 Cadillac Escalade? Posted by Customer
    A:
    Ensure the ignition is turned OFF before inserting fingers into the throttle bore.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    How can you verify the throttle actuator motor electrical connector is properly installed for the 2005 Cadillac Escalade EXT? Posted by Customer
    A:
    Ensure that the connector and seal are properly installed and undamaged.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    Why is it important to turn off the ignition for the 2004 Cadillac Escalade ESV? Posted by Customer
    A:
    To prevent unexpected movement of the throttle blade, which could cause personal injury.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What should be done to test the throttle operation for the 2006 Chevrolet Avalanche 2500? Posted by Customer
    A:
    Connect a scan tool to test for proper throttle-opening and throttle-closing range.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    How can these deposits affect performance for the 2003 Chevrolet Avalanche 1500? Posted by Customer
    A:
    They can affect pedal effort or throttle valve movement, particularly in vehicles with mileage over 80450 km (50,000 mi).
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What connectors need to be disconnected during the process for the 2007 Chevrolet Express 2500? Posted by Customer
    A:
    The throttle position (TP) sensor and idle air control (IAC) valve harness connectors.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What electrical connectors need to be disconnected for the 2005 Chevrolet Express 3500? Posted by Customer
    A:
    The throttle position (TP) sensor and idle air control (IAC) valve harness connectors.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What should be done after placing the new throttle body for the 2007 Chevrolet Silverado 1500 Classic? Posted by Customer
    A:
    Install the throttle body studs, tightening them to 9 N.m (80 lb in).
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What is the final step before starting the engine for the 2004 Chevrolet Silverado 2500? Posted by Customer
    A:
    Refill the cooling system, then connect a scan tool to test the throttle-opening and throttle-closing range.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What should be connected to test the throttle operation for the 2007 Chevrolet Silverado 3500 Classic? Posted by Customer
    A:
    A scan tool to test the throttle-opening and throttle-closing range.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What is the installation process for the new throttle body for the 2005 Chevrolet Suburban 1500? Posted by Customer
    A:
    Place a new throttle body gasket, install the throttle body, and tighten the nuts to 10 N.m (89 lb in).
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What is the first step in the installation process for the 2005 Chevrolet Silverado 1500? Posted by Customer
    A:
    Place a new throttle body seal and the throttle body.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What should be inspected after starting the engine for the 2006 Chevrolet Silverado 3500? Posted by Customer
    A:
    Inspect for coolant leaks.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What components need to be removed after draining the cooling system for the 2004 Chevrolet SSR? Posted by Customer
    A:
    Remove the air cleaner outlet duct and the engine sight shield.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What should be connected after installing the throttle body for the 2002 Chevrolet Tahoe? Posted by Customer
    A:
    Connect the coolant hose to the throttle body and the vapor vent pipe, followed by the accelerator control cable and cruise control cable.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    How should the throttle operation be inspected for the 2002 Chevrolet Suburban 2500? Posted by Customer
    A:
    With the vehicle not in reduced engine power, turn on the ignition with the engine off to inspect for complete throttle opening and closing positions, using a scan tool to monitor the throttle angles while operating the accelerator pedal.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What should be reconnected after installing the throttle body for the 2005 GMC Savana 2500? Posted by Customer
    A:
    The coolant hoses, accelerator control cable, cruise control cable, TP sensor, IAC valve electrical connectors, and vacuum hose.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What should be reconnected after installing the throttle body for the 2005 GMC Savana 3500? Posted by Customer
    A:
    The coolant hoses, accelerator control cable, cruise control cable, TP sensor, IAC valve electrical connectors, and vacuum hose.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What should be used to clean the throttle body for the 2006 GMC Sierra 3500? Posted by Customer
    A:
    Clean the throttle body bore and the throttle plate with a clean shop towel using GM top engine cleaner (P/N 1052626) or AC Delco Carburetor Tune-up Conditioner (P/N X66P) or an equivalent product.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What is the next step after disconnecting the electrical connectors for the 2007 GMC Sierra 1500 Classic? Posted by Customer
    A:
    Remove the throttle body studs and the throttle body itself, discarding the throttle body seal.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What is the final step after cleaning the throttle body for the 2004 GMC Yukon? Posted by Customer
    A:
    Reinstall the air cleaner intake duct.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What should be done with the coolant air bleed hose for the 2005 GMC Sierra 1500? Posted by Customer
    A:
    Reposition the coolant air bleed hose clamp and remove the coolant air bleed hose from the throttle body.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What is the first step in the replacement process for the 2007 GMC Sierra 3500 Classic? Posted by Customer
    A:
    Remove the air cleaner outlet duct.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    Q:
    What products can be used to clean the throttle body bore and throttle plate for the 2004 GMC Yukon XL 2500? Posted by Customer
    A:
    GM Top Engine Cleaner (P/N 1052626), AC-Delco Carburetor Tune-Up Conditioner (P/N X66-P), or an equivalent product.
    Posted by ChevyPartsDeal Specialist
    See vehicle specific detailed answers for this Throttle Body
    If you have any questions about this product, please don't hesitate to ask us. We will be happy to help you!

OEM GM Throttle Body 19420713 Designed for Proper Fit and Performance

Original OEM GM parts deliver superior quality and meet all performance standards needed for optimal automotive operation. The authentic part identified by 19420713 Throttle Body is available in the market under the name GM Throttle Body. This genuine product has a full warranty coverage from the manufacturer available at all authorized GM dealers throughout the United States. This part 19420713 Throttle Body fits certain Chevrolet Tahoe, SSR, Silverado 1500 models, as well as GMC Sierra 1500, Yukon, Sierra 2500 HD. Additionally, it is compatible with Cadillac Escalade, Escalade ESV, Escalade EXT and Buick Rainier models.
The original GM component designated by Manufacturer Part Number 19420713 maintains top performance when functioning as the Body, Fuel Injection Air Meter unit. The component 19420713 is constructed from durable material. The component is ready in New condition to ensure full compatibility with your vehicle system. The part 19420713 has available replacement options 12679525, 12570800. GM manufacturer provides a warranty that ensures reliable operation of this product. The Shipping Policy and Return Policy pages outline complete details regarding shipping procedures and return processes.
If you want to save money in the long run on maintenance and repairs, you should choose OEM products because they're of the top level of durability. Are you on the quest of finding GM parts? Our site is worth a visit. We stock an endless selection of high-quality GM components including things like ignition coils all the way through to fan shrouds and all at prices that can not be matched. You have nothing to worry about because all our OEM parts are covered with a manufacturer warranty, which guarantees superior quality and value.
