How to replace the cellular communications/digital radio antenna on Cadillac STS?

In order to replace the cellular communications/digital radio Antenna, start by removing the rear sail panels. Take care not to hurt the headliner when removing or installing since excessive bending can destroy the headliner. Lower the rear side of the headliner, and then removing the foam tape behind the Antenna cable connection. Remove the Antenna connectors, disconnect the bolts and expansion sleeve and remove the Antenna. Then, unscrew the screws on which the Antenna mast is connected to the Antenna Base and disconnect the mast. To install, mount the Antenna on the roof and ensure that the wiring pigtail is routed to the side in the slot on the Antenna shat. Follow a sequence of steps where you install the Antenna expansion sleeve and bolt to the Antenna shaft, screwing it to 9 nm (80 lb in). Connect the Antenna connectors back and cover them with a foam tape. Mount the Antenna cable connection to the am/fm Antenna module and secure the Antenna to hold down clips. Synchronize the headliner to the roof panel, and attach the rear sail panels. Finally, put the mast on the Antenna Base and attach it with screws, tighten the screws up to 1 nm (9 lb in).

OEM Cadillac STS Antenna

Radio Antenna

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

8 Antennas found

View related parts
Cadillac STS Antenna Mast Part Number: 20842596
$31.44 MSRP: $59.00
You Save: $27.56 (47%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Antenna, Power Radio Antenna; Antenna; Mast; Antenna, Vehicle Navigation/Information; Antenna, Radio Antenna
- Replaces: 10335503, 25912948
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2005-2008 Cadillac STS | Base, Platinum, V | 6 Cyl 3.6 L GAS, 8 Cyl 4.4 L GAS, 8 Cyl 4.6 L GAS
View related parts
Cadillac STS Antenna Assembly Part Number: 25751331
$105.72 MSRP: $191.33
You Save: $85.61 (45%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Antenna Assembly-Digital Radio & Mobile Telephone & Vehicle; Base; Antenna
- Replaced by: 25775153
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2005-2008 Cadillac STS | Base, Platinum, V | 6 Cyl 3.6 L GAS, 8 Cyl 4.4 L GAS, 8 Cyl 4.6 L GAS
View related parts
Cadillac STS Antenna, Gray; Red Part Number: 25831358
Product Specifications
- Replaced by: 25831355
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2009-2011 Cadillac STS | Base, Platinum, V | 6 Cyl 3.6 L GAS, 8 Cyl 4.4 L GAS, 8 Cyl 4.6 L GAS
View related parts
Cadillac STS Antenna, Black, Carbon Part Number: 25831350
Product Specifications
- Other Name: Antenna, Vehicle Navigation/Information
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2009-2010 Cadillac STS | Base, Platinum, V | 6 Cyl 3.6 L GAS, 8 Cyl 4.4 L GAS, 8 Cyl 4.6 L GAS
View related parts
Cadillac STS Antenna Part Number: 25831355
Product Specifications
- Other Name: Antenna, Power Radio Antenna; Antenna, Vehicle Navigation/Information; Antenna, Radio Antenna
- Replaces: 25831351, 25831353, 25831349, 25831352, 25831356, 25831359, 25831358, 25831354
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2009-2011 Cadillac STS | Base, Platinum, V | 6 Cyl 3.6 L GAS, 8 Cyl 4.4 L GAS, 8 Cyl 4.6 L GAS
View related parts
Cadillac STS Antenna Mast Part Number: 25758073
Product Specifications
- Other Name: Antenna, Radio Antenna; Antenna Assembly; Antenna; Antenna, Vehicle Navigation/Information
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2005 Cadillac STS | Base | 6 Cyl 3.6 L GAS, 8 Cyl 4.6 L GAS
View related parts
Cadillac STS Antenna Part Number: 25730079
$20.78 MSRP: $37.10
You Save: $16.32 (44%)
Product Specifications
- Other Name: Antenna, Ignition Lock Key Xmeter; Antenna,Theft Deterrent Or Front/Rear/Side/Intake Object
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2005-2011 Cadillac STS | Base, Platinum, V | 6 Cyl 3.6 L GAS, 8 Cyl 4.4 L GAS, 8 Cyl 4.6 L GAS
View related parts
Cadillac STS Antenna Part Number: 15828833
$15.65 MSRP: $27.94
You Save: $12.29 (44%)
Product Specifications
- Other Name: Antenna Assembly-Navigation; Antenna, Vehicle Navigation/Information
- Replaces: 25726569
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2005-2011 Cadillac STS | Base, Platinum, V | 6 Cyl 3.6 L GAS, 8 Cyl 4.4 L GAS, 8 Cyl 4.6 L GAS

Cadillac STS Antenna

Want to cut long-term maintenance and repair costs? Choose OEM Antenna. Those parts deliver top durability you can trust. On our site, you'll find a huge catalog of genuine Cadillac STS parts. Prices are unbeatable, so you can keep more in your pocket. Every OEM Cadillac STS Antenna includes a manufacturer's warranty. You can also get an easy return policy that keeps buying risk free. Fast delivery, get your car on the road quickly. It's simple to search, compare, and order. Stop guessing about quality or fit. Order today and save with parts that last.

Use of the Cadillac STS Antenna transforms Cadillac STS vehicles into superior performing systems which deliver dependable radio reception for entertainment and communication across different satellite platforms. Produced for maximum durability the Cadillac STS Antenna works across STS models including Northstar V8 engine models. The antenna system offers three styles-internal, external and satellite-and fulfills separate functions to optimize security and performance. The manufacturer uses metal or fiberglass material for external antennas to position them optimally for signal strength enhancement while roof-mounted satellite antennas deliver superior sound quality. Cadillac demonstrates its commitment to both innovation and thetic appeal through its progressive evolution from manual adjustable extended antennas to present-day sleek profile designs of the STS Antenna model series. The unit transition improves vehicle design alongside providing drivers an unbroken pathway for audio and communication access. Anyone who owns a Cadillac model requires the component because it has emerged as the top market choice based on its remarkable performance capabilities and exceptional reliability. The car part enables advanced safety features through its capabilities and provides advanced functions which make the driving experience superior while reinforcing the automaker's market position as a luxury automaker.

Cadillac STS Antenna Parts and Q&A

Antenna
15828833
Q: How to replace the cellular communications/digital radio antenna on Cadillac STS?
A:
In order to replace the cellular communications/digital radio Antenna, start by removing the rear sail panels. Take care not to hurt the headliner when removing or installing since excessive bending can destroy the headliner. Lower the rear side of the headliner, and then removing the foam tape behind the Antenna cable connection. Remove the Antenna connectors, disconnect the bolts and expansion sleeve and remove the Antenna. Then, unscrew the screws on which the Antenna mast is connected to the Antenna Base and disconnect the mast. To install, mount the Antenna on the roof and ensure that the wiring pigtail is routed to the side in the slot on the Antenna shat. Follow a sequence of steps where you install the Antenna expansion sleeve and bolt to the Antenna shaft, screwing it to 9 nm (80 lb in). Connect the Antenna connectors back and cover them with a foam tape. Mount the Antenna cable connection to the am/fm Antenna module and secure the Antenna to hold down clips. Synchronize the headliner to the roof panel, and attach the rear sail panels. Finally, put the mast on the Antenna Base and attach it with screws, tighten the screws up to 1 nm (9 lb in).
